3" Sieve, All Stainless, Full Height 2

Gilson Testing Screens are ideal for particle size determinations on large samples of aggregate, slag, ores, and other coarse materials. Batch sizes up to one cubic foot (28.3L) or more can be processed into six fractions in as little as six to ten minutes, depending on the material type.

Vibration and amplitude characteristics are fixed at optimum levels for mineral aggregates in the 4in (101mm) to No.4 (4.75mm) size range, but options and accessories are available for testing finer samples or special materials. Testing Screen models have the same performance characteristics but differ in the clamping mechanism, safeguarding devices, number of tray slots, and operational convenience features.

The drive mechanism is completely enclosed for added safety, and the powerful 1/2hp capacitor-type motor is operated with a starting switch with built-in overload protection. Independently removable Screen Trays and Dustpans are purchased separately and shared by both Testing Screen and Test-Master® models. The Trays have replaceable Screen Cloth and are available in a wide range of opening sizes with ASTM E11 and ISO 565 wire cloth or punched steel plate.

Gilson Testing Screens are designed to be securely bolted to a concrete or rigid floor system. They feature a manual hydraulic pump for easy tray clamping, a top-mounted enclosed drive mechanism, and a 1/2hp capacitor motor with overload protection for safe operation. Both the TS-1 and TS-3 models offer a simple On/Off switch.

Convenience, repeatability, and accuracy can be improved by connecting the Testing Screen to an optional TSA-169R Digital Lab Timer. The TS-4 includes an integrated digital timer/controller for streamlined operation.

TS-1 Gilson Testing Screen uses a quick-acting hydraulic pump system to clamp the screen trays in place. Trays are quickly released using the same handle. A total of six tray slots hold five Screen Trays plus a dustpan.

TS-3 Gilson Testing Screen features an additional tray slot for samples requiring additional fractions. Seven tray slots hold six Screen Trays plus a dustpan.

TS-4 Gilson Silent Testing Screen combines all the features of the TS-3 with a sound-damping structure, integrated LED timer, heavy-duty latch, ferrite magnets, wear-resistant seals, and sound-damping material to significantly reduce operational noise.

Features

• Rapid particle size determinations for materials from 4in (101mm) to No.4 (4.75mm).
• The enclosed drive mechanism promotes safety during operation.
• Processes large samples up to 1ft³ (28.3L).

Included Items

• Gilson Testing Screen

Accessories

• Screen Trays with ASTM or ISO Wire Cloth or Punched Plate openings.
• Additional Dustpans (standard, 4in deep, 3in deep, or inclined chute).
• Door Enclosures minimize dust and noise.
• TSA-156 Screen Tray Storage Rack.
• TSA-167 Clean-N-Weigh Accessory.
• TSA-180 Sound Enclosure.
• Hydraulic Clamping Conversion Kit.
• TSA-169R Digital Lab Timer.
• TSA-154R Speed Variation Accessory.
• TSA-200 Low-Amplitude Drive Shaft.
